Description
Bently 3500-15-05-05-0
Technical Specifications
- Product Series: 3500 Machinery Protection System
- Input Voltage: 115 VAC or 230 VAC (selectable)
- Output Voltage: Regulated DC for rack modules
- Configuration: Custom variant indicated by suffix
Functional Features
- Custom Configuration: Tailored for applications requiring specific power supply characteristics or options.
- Redundant Capability: Supports redundant power supply configuration for enhanced system reliability.
- Status Monitoring: Provides power supply health status to the system.
Application Scenarios
Utilized across power generation, petrochemical processing, and heavy manufacturing for powering 3500 monitoring systems with specialized requirements.
Performance Parameters
- Operating Temperature Range: -40°C to +85°C (-40°F to +185°F)
- Power Consumption: Optimized for efficient operation
- Protection: Over-voltage, over-current, and short-circuit protection
Material Composition
Housed in a rugged, shielded metal enclosure to provide complete EMI/RFI shielding and environmental protection.
Structural Characteristics
Features front-panel status LEDs and rear connectors for AC input and DC output distribution.
Working Principle
Converts AC line power to regulated DC power for the 3500 rack modules through internal switching power supply circuitry.
Installation Requirements
Install in the designated power supply slot in the 3500 rack. Ensure proper AC input connection and grounding.
Usage Precautions
Verify that the input voltage selector matches the available AC power source. Never remove the power supply while the system is energized.
