Description
Bently 3500/15 106M1079-01
Technical Specifications
- Module Type: 3500 Power Supply
- Part Number: 106M1079-01
- Input Voltage: 85 to 264 VAC or 125 VDC
- Output Voltage: Regulated DC for 3500 backplane
Functional Features
- Universal Input: Accepts a wide range of AC or DC input voltages, accommodating global power standards.
- Redundancy Support: Designed to operate in parallel with a second 3500/15 module for high-availability, redundant power configurations.
- Hot-Swappable: Can be replaced without powering down the 3500 rack or interrupting machinery protection.
Application Scenarios
Installed in the first slot of every 3500 full-height or mini frame, providing the essential power backbone for all monitoring and protection modules.
Performance Parameters
- Power Consumption: < 15 Watts
- Isolation: High-voltage isolation between input and output
- Operating Temp: -30°C to +65°C
Material Composition
Industrial-grade electronic components, conformal-coated PCBs, and a ruggedized metallic shielding enclosure.
Structural Characteristics
Standard full-height 3500 rack module with front-panel status LEDs and rear high-density backplane connectors.
Working Principle
Converts incoming AC/DC power to regulated DC voltages (+5V, +12V, -12V, etc.) distributed through the 3500 backplane to all installed modules.
Installation Requirements
Must be installed in the designated power supply slot (usually slot 1). Ensure the backplane connector is fully seated and secure the front panel mounting screws.
Usage Precautions
Never remove or insert the module while the rack power is energized unless performing a hot-swap procedure. Always use the 3500 Rack Configuration Software to verify power supply health.
