Description
Bently 3500 22M-01-01-00
Technical Specifications
- Module Type: Enhanced TDI (M-Series)
- Configuration: Standard (01-01-00)
- Network Interface: 10/100 Base-TX Ethernet
- Slot Requirement: Slot 1
Functional Features
- System Integration: The definitive link between 3500 hardware and System 1 mechanical management software.
- Flexible Data Capture: Standard static data capture with optional dynamic/transient capture via Channel Enable Disks.
- Robust Communication: Handles continuous data streaming without impacting the core protection logic of the rack.
Application Scenarios
The standard communication module for virtually all modern 3500 machinery protection and condition monitoring systems worldwide.
Performance Parameters
- Operating Temperature: -30°C to +65°C
- Storage Temperature: -40°C to +85°C
- Humidity: 95% non-condensing
- Power Consumption: Typical 10.5 Watts
Material Composition
Industrial-grade electronics with EMI shielding and conformal coating.
Structural Characteristics
Full-height module with RJ-45 Ethernet port, USB-B configuration port, and comprehensive LED status indicators.
Working Principle
Aggregates data from all M-series monitors in the rack and routes it to the host software via TCP/IP Ethernet.
Installation Requirements
Must occupy Slot 1. Connect to a 10/100 Base-TX network switch using shielded Ethernet cabling.
Usage Notes
The TDI is not a critical protection component; if it fails, the machinery protection relays will continue to operate normally, but remote monitoring and waveform capture will be lost.
