Description
Bently 3500 33-01-00
Technical Specifications
- Model Number: 3500/33-01-00
- Channel Count: 16 independent relay channels
- Configuration: Factory-specified regional/certification variant
Key Features
- Customized Compliance: Meets specific regional safety standards or customer-specified contact rating requirements.
- High-Density Output: Provides 16 programmable SPDT relays in a single module footprint.
- Advanced Logic: Supports complex AND/OR voting and channel inhibiting via 3500 Configuration Software.
Application Scenarios
Used in specialized industrial facilities where specific electrical certifications or customized relay contact materials are required for compliance with local safety regulations.
Performance Parameters
- Contact Rating: Customized based on the “-01-00” configuration
- Environmental Sealing: Epoxy-sealed for arc suppression
Material Composition
Industrial-grade metallic and polymeric materials selected to meet specific environmental and electrical certification standards.
Structural Characteristics
Full-height module with 16 front-panel status LEDs. Identical physical dimensions to standard 3500/33 modules for seamless rack integration.
Working Principle
Evaluates backplane alarm signals against user-configured logic and actuates the corresponding relay contacts, providing isolated, hardware-level protection outputs.
Installation Requirements
Install in any available slot to the right of the TDI module. Ensure external wiring matches the specific contact ratings defined by the “-01-00” configuration.
Usage Precautions
Consult the specific datasheet for the “-01-00” variant to verify exact contact ratings and approved applications. Do not substitute with standard 3500/33 modules if specific certifications are mandated.
