Bently 3500/33-01
Technical Specifications
- Module Type: 16-Channel Relay Module
- Configuration Code: 01 (Base Configuration)
- Channel Count: 16 independent relay outputs
- Slot Placement: Any available monitor slot
Functional Features
- Space Efficiency: Consolidates 16 relay outputs into a single module slot.
- Flexible Logic Mapping: Relay states can be mapped to any combination of alarm, danger, or module fault conditions via configuration software.
- Standard Industrial Component: Provides reliable switching for plant-wide integration.
Application Scenarios
Widely used in large power plants, petrochemical facilities, and manufacturing plants for comprehensive condition monitoring and protection of rotating machinery.
Performance Parameters
- Operating Temperature Range: -30°C to +65°C
- Storage Temperature Range: -40°C to +85°C
- Humidity: 95% non-condensing
Material Composition
Industrial-grade electromechanical relays with gold-plated contacts for reliable low-level signal switching.
Structural Characteristics
Full-height module with front-panel LEDs indicating the status of each relay channel.
Working Principle
Receives logic signals from the rack backplane and energizes/de-energizes relay coils to switch external contacts based on configured logic.
Installation Requirements
Install in any available monitor slot. Ensure external wiring is properly terminated.
Usage Notes
Verify the complete ordering code, including any suffixes, to ensure compatibility with the existing system.
