Description
Bently 3500/42-04-CN
Technical Specifications
- Module Type: 4-Channel Position Monitor Module with Safety Barrier
- Configuration: 04 (Safety Barrier)
- Regulatory Approval: CN (China National Standards)
- Channel Count: 4 independent channels
Functional Features
- Domestic Compliance: Fully certified for use in Chinese industrial facilities.
- Intrinsic Safety: Built-in safety barriers eliminate the need for external Zener barriers or isolators.
- Standard Functionality: Provides reliable position measurement in hazardous areas.
Application Scenarios
Mandatory for domestic power plants, state-owned enterprises, and large-scale infrastructure projects in China where equipment must pass strict local safety and compliance inspections in hazardous areas.
Performance Parameters
- Operating Temperature Range: -30°C to +65°C
- Storage Temperature Range: -40°C to +85°C
- Humidity: 95% non-condensing
- EMC Rating: Compliant with Chinese industrial EMC standards
Material Composition
Manufactured using components that comply with domestic environmental and safety regulations.
Structural Characteristics
Full-height module with CN certification labeling and safety barrier markings.
Working Principle
Processes proximity probe signals through internal safety barriers to generate position measurements in hazardous areas.
Installation Requirements
Install in an available monitor slot. Follow Chinese electrical grounding standards and hazardous area procedures.
Usage Notes
Do not substitute non-CN modules in projects strictly requiring CN-certified components, as this may cause compliance failures during official audits.
