Description
Bently 9200-06-05-05-00
Technical Specifications
- Sensor Type: Two-Wire Velocity Seismic Sensor
- Part Number: 9200-06-05-05-00
- Certification: 05 (Multiple Agency Approvals)
- Cable Length: 5 feet (approx. 1.5 meters)
Functional Features
- Compact Cable Length: The 5-foot cable is ideal for applications where the monitor or VDC is located close to the sensor.
- High Performance: Delivers excellent accuracy and repeatability for continuous machinery protection.
- Universal Compatibility: Works seamlessly with 3500 series monitors and 9513 Velocity-Displacement Converters.
Application Scenarios
Perfect for localized casing vibration monitoring on pumps, motors, and fans where the junction box or monitor is in close proximity.
Performance Parameters
- Sensitivity: 20 mV/mm/s (500 mV/in/s) ±5% at 100 Hz
- Frequency Response: Up to 1 kHz (60,000 cpm)
- Operating Temperature: -29°C to +121°C
Material Composition
Standard industrial-grade metals and shielded cabling.
Structural Characteristics
Standard cylindrical form factor with integrated short-length cable.
Working Principle
Electromagnetic induction generates a voltage output directly proportional to the velocity of the structural vibration.
Installation Requirements
Securely mount to a clean, flat machined surface. Route the short cable to avoid tension on the sensor connector.
Usage Precautions
Do not use extension cables to lengthen the 5-foot integrated cable, as this may degrade the signal and introduce noise. Select a longer part number if needed.
