Product Overview: The 3300/61-04-01-01-00-00-00 is an operator display unit within the Bently Nevada 3300/3500 machinery protection system ecosystem. It provides a VGA touchscreen interface for displaying real-time 3500 system data, enabling operators to monitor machinery condition, view alarm status, configure parameters, and access historical data directly at the machine site.

Request Quote
Category:

Description

Bently Nevada 3300/61-04-01-01-00-00-00

Technical Specifications:

  • Display Type: VGA monitor with touchscreen capability
  • Power Consumption (Display Unit -01): 5.6 watts
  • Power Consumption (Display Unit -02): 12.0 watts
  • Power Consumption (Display + Interface Module): 15.5 watts maximum
  • Dimensions: 200mm × 200mm × 100mm
  • Weight: 0.55 kg
  • Compatibility: Up to two displays per 3500 rack

Functional Features:

  • Touchscreen operation for intuitive parameter setting and data query
  • Real-time display of 3500 system vibration, displacement, speed, and temperature data
  • Customizable display interface — users select which data and graphics to show
  • Real-time alarm display for immediate fault notification
  • Historical data recording for trend analysis and troubleshooting
  • Multiple mounting options for flexible installation

Application Scenarios:

  • On-site operator monitoring of critical rotating machinery
  • Power plant control rooms displaying turbine and generator condition
  • Petrochemical facilities requiring local machinery status display
  • Any 3500 system installation where local visual monitoring is required

Performance Parameters:

  • Display resolution: VGA standard
  • Touchscreen: Responsive touch input for navigation
  • Data refresh: Real-time update from 3500 rack

Material Composition:

  • Industrial-grade display panel
  • Rugged enclosure suitable for industrial environments

Structural Features:

  • Compact form factor for space-efficient installation
  • Four mounting options: face mount, 19-inch EIA rack mount, panel mount, and standalone mount
  • Display interface module connects to 3500 rack

Working Principle:
The 3300/61 connects to the 3500 rack via a display interface module, receiving real-time process data from all monitoring channels in the rack. The display unit renders this data in customizable graphical and numerical formats on the VGA screen, allowing operators to interact with the system through the touchscreen interface.

Installation Requirements:

  • Mount using one of the four supported mounting methods
  • Connect display interface module to the 3500 rack
  • Configure display parameters using the touchscreen interface
  • Maximum two display units per 3500 rack

Usage Notes:

  • Verify compatibility with the specific 3500 rack firmware version
  • The -01 display unit consumes less power (5.6W) compared to the -02 unit (12.0W)
  • Ensure adequate ventilation around the display unit for thermal management
