Product Introduction: The 330103-00-13-10-02-CN is a proximity probe belonging to the Bently Nevada 3300 XL 8mm eddy current sensor system. It is a non-contact sensor designed for measuring shaft radial vibration, axial displacement, keyphasor signals, rotational speed, eccentricity, and differential expansion on rotating machinery. The probe operates as part of a three-component system together with a 3300 XL extension cable and a 3300 XL Proximitor sensor. It is widely used in power generation, petrochemical, metallurgical, and general industrial applications for online condition monitoring and machinery protection.

Request Quote
Category:

Description

Bently Nevada 330103-00-13-10-02-CN

Technical Specifications:

  • Probe Diameter: 8 mm
  • Mounting Thread: M10×1 metric thread
  • Sensitivity: 7.87 V/mm (200 mV/mil)
  • Linear Range: 2 mm (0.25 mm to 2.3 mm gap, equivalent to 10 mils to 90 mils)
  • Frequency Response: 0 to 10 kHz
  • Recommended Gap Setting: 1.27 mm (50 mils), corresponding to approximately -10 Vdc output
  • Operating Temperature (Probe Tip): -51°C to +177°C (-60°F to +350°F)
  • Cable Length Code: 13 indicates a specific probe cable length configuration; the total system length (probe cable + extension cable) must equal 5.0 m or 9.0 m
  • Connector Type: ClickLoc gold-plated coaxial connector (code 02)
  • Certification: CN suffix indicates compliance with Chinese regional standards
  • Protection Rating: IP67 (probe body)
  • Compliance: API 670 standard

Functional Features:

  • Non-contact eddy current measurement provides sub-micron displacement resolution without mechanical wear
  • Simultaneously capable of dynamic vibration measurement and static displacement monitoring
  • Compatible with Bently Nevada 3500, 2300/20, and 1900/65A monitoring systems
  • Interchangeable within the 3300 XL 8mm system without individual calibration
  • ClickLoc connector provides secure, tool-free connection with IP67 environmental sealing
  • Designed for installation in bearing housings of oil-film bearing machinery

Application Scenarios:

  • Steam turbines and gas turbines for shaft vibration and axial displacement monitoring
  • Centrifugal compressors and pumps for radial vibration protection
  • Generators and large motors for bearing condition assessment
  • Gearboxes for shaft vibration measurement
  • Fans, blowers, and expanders in power, petrochemical, and metallurgical plants
  • TSI (Turbine Supervisory Instrumentation) systems in power generation

Performance Parameters:

  • Sensitivity: 7.87 V/mm ±5% (standard 5m system) or ±6.5% (standard 9m system)
  • Linearity: ±1% full scale
  • Resolution: 0.1 μm
  • Frequency Response: DC to 10 kHz
  • Output: Analog voltage proportional to gap distance

Material Composition:

  • Probe Housing: AISI 303/304 stainless steel
  • Probe Tip: PPS (polyphenylene sulfide) engineering plastic encapsulation over ferrite core
  • Cable: FEP-insulated coaxial cable with ClickLoc gold-plated copper connectors
  • Seals: Viton O-ring

Structural Features: Cylindrical 8mm diameter probe body with M10×1 threaded mounting section. The probe features an integrated cable with a ClickLoc connector at the cable end for connection to the extension cable. The probe tip is molded with PPS for mechanical protection and electrical insulation.

Working Principle: The probe contains a high-frequency oscillating coil (typical center frequency 1-2 MHz) at its tip. When positioned near a conductive metal target (the rotating shaft), the alternating magnetic field induces eddy currents on the shaft surface. These eddy currents generate a counter magnetic field that interacts with the probe coil, changing its effective impedance. The impedance change is directly proportional to the gap between the probe tip and the shaft surface. The Proximitor electronics demodulate this impedance change into a DC voltage output that is linearly proportional to the gap distance. Static gap changes produce DC voltage shifts (displacement measurement), while dynamic gap variations produce AC voltage superimposed on the DC level (vibration measurement).

Installation Requirements:

  • Mount the probe in a standard M10×1 threaded bracket or bearing housing
  • Use a torque wrench set to 1.7 to 2.3 N·m for final tightening
  • Ensure the probe is perpendicular to the shaft surface with angular deviation within 3°
  • The total system cable length (probe + extension cable) must be exactly 5.0 m or 9.0 m
  • Connect to a compatible 3300 XL Proximitor (e.g., 330180 series) via the extension cable
  • Adjust the static gap to produce a Proximitor output of -10.0 Vdc ± 0.2 Vdc
  • Route signal cables at least 30 cm away from high-voltage power cables
  • Shield grounding must be single-point only (at the Proximitor or monitor end)

Usage Notes:

  • The target surface must be AISI 4140 steel or a material for which the Proximitor has been specifically calibrated
  • The target surface must be smooth, clean, and free of oil, paint, or plating; surface roughness better than 1.6 μm
  • Never power on or replace the probe while the system is energized
  • Verify cable integrity and connector tightness during each maintenance interval
  • The CN suffix confirms Chinese market compliance; verify local certification requirements before installation
  • Gap voltage adjustment must be performed with the machine at rest (cold state)
