Description
Bently Nevada 330104-08-16-05-02-05
Technical Specifications:
- Product Series: 3300 XL 8mm Eddy Current Sensor System
- Probe Diameter: 8mm
- Thread Specification: 3/8-24 UNF Imperial Thread
- Unthreaded Length: 08 = 80mm
- Overall Case Length: 16 = 160mm
- Total Cable Length: 05 = 0.5 meters
- Connector Type: 02 = Miniature coaxial ClickLoc connector, standard cable
- Agency Approval: 05 = Multiple certifications
Functional Features:
- Armored cable design resists wear, crushing, and chemical corrosion
- Non-contact measurement eliminates mechanical wear
- High-quality inductors and high-precision resistors with multi-stage shielding structure
- High-frequency low-pass filter prevents AC signal interference
- Complies with API 670 standard
- Fully interchangeable with 3300 XL proximitor modules and extension cables
Application Scenarios:
- Rotating machinery vibration monitoring in harsh environments
- Petrochemical industry compressor and pump monitoring
- Metallurgical industry blast furnace fan shaft vibration monitoring
- Long-term stable monitoring in environments containing iron filings and oil
- Applications requiring mechanical protection with armored configuration
Performance Parameters:
- Sensitivity: 7.87 V/mm (200 mV/mil)
- Linear Range: 2mm (80 mils)
- Frequency Response: 0 to 10 kHz
- Supply Voltage: -17.5 VDC to -26 VDC, maximum 12mA
- Probe Operating Temperature: -52°C to +177°C (standard type)
- Recommended Gap Setting: 1.27mm (50 mils)
Material Composition:
- Probe Tip: PPS Polyphenylene Sulfide
- Probe Housing: AISI 303 or 304 stainless steel
- Cable: Armored stainless steel braided sheath
Structural Features:
- 3/8-24 UNF imperial thread mounting
- Long housing design (160mm) suitable for deep-hole installation
- Armored stainless steel braided cable sheath
- ClickLoc miniature coaxial connector
Working Principle: Eddy current effect — the probe coil generates a high-frequency alternating magnetic field. The conductive target surface induces eddy currents, and the reverse magnetic field from these eddy currents alters the coil impedance. The proximitor converts this impedance change into a voltage signal proportional to the gap.
Installation Requirements:
- The mounting hole must be machined with 3/8-24 UNF internal thread
- Total system length must match the proximitor
- Armored cable bending radius must meet minimum requirements
- Set gap voltage to -10.0 VDC ± 0.2V
Usage Precautions:
- The armor layer must not be damaged, as this compromises shielding effectiveness
- Cable bending radius must exceed the minimum required value
- Do not replace the probe while energized
- Hand-tighten the connector only; do not overtighten
