Description
Bently Nevada 330130-085-03-05
Technical Specifications
- Model: 330130-085-03-05
- Series: 3300 XL Proximity Transducer System
- Cable Length: 8.5 meters (27.9 feet)
- Connector Protector and Cable Option: 03 — Armored cable with connector protectors
- Agency Approval: 05 — Multiple approvals (CSA, ATEX, IECEx)
- Cable Construction: 75 Ω triaxial, Fluorinated Ethylene Propylene (FEP) insulated with armor
- Capacitance: 69.9 pF/m (21.3 pF/ft) typical
- Operating Temperature: -51°C to +177°C (-60°F to +350°F)
- Weight: Approximately 0.948 kg
- Connector Type: Gold-plated ClickLoc miniature coaxial connectors with protectors
Function Features
- Armored construction provides superior mechanical protection
- Connector protectors prevent oil and moisture ingress
- Multiple hazardous area certifications for global deployment
- Gold-plated ClickLoc connectors for secure electrical contact
- Complete interchangeability within 3300 XL system
- Backward compatibility with non-XL components
Application Scenarios
- Critical machinery monitoring in hazardous industrial environments
- Turbine supervisory instrumentation in oil and gas applications
- Compressor protection systems requiring armored cables
- Keyphasor and speed measurement in harsh conditions
- Power generation equipment in explosive atmospheres
Performance Parameters
- Extension cable capacitance is 69.9 pF/m typical
- System accuracy is maintained over full cable length
- Impedance is matched to 3300 XL transducer requirements
- Signal fidelity preserves dynamic and static signals
- Temperature stability provides consistent performance
Material Composition
- Cable jacket is Fluorinated Ethylene Propylene (FEP) with stainless steel armor
- Armor is flexible AISI 302 stainless steel
- Conductors are copper with precision impedance characteristics
- Connectors are gold-plated brass or beryllium copper
Structural Characteristics
- Armored cable with connector protectors
- Triaxial design for EMI/RFI immunity
- ClickLoc gold-plated connectors
- Connector protectors on female end
- Crush-resistant and abrasion-resistant construction
Installation Requirements
- Ensure combined probe and cable length matches Proximitor calibration
- Install with minimum 25.4 mm bend radius
- Secure cable along routing path to prevent strain
- Separate from high-voltage cables to prevent interference
- Verify proper ClickLoc connector engagement
Operating Considerations
- Suitable for hazardous areas with CSA, ATEX, and IECEx approvals
- Inspect armor integrity during routine maintenance
- Verify connector protectors are properly seated
- Replace if armor or cable jacket shows damage
- Maintain connector cleanliness for optimal performance
