Description
Bently Nevada 330171-00-40-10-02-00
Technical Specifications:
- Product Series: 3300 5mm Eddy Current Sensor System
- Probe Diameter: 5mm
- Thread Specification: 1/4-28 UNF Imperial Thread
- Unthreaded Length: 00 = 0.0 inches
- Overall Case Length: 40 = 0.4 inches
- Total Cable Length: 10 = 1.0 meter
- Connector Type: 02 = Miniature coaxial ClickLoc connector, standard cable
- Agency Approval: 00 = Not required
Functional Features:
- Compact 5mm probe diameter for space-constrained installations
- Patented TipLoc molding method provides robust bond between probe tip and probe body
- FluidLoc cable option available for preventing oil and liquid leakage through cable interior
- Corrosion-resistant gold-plated brass ClickLoc connectors require only finger-tight torque
- Specially engineered locking mechanism prevents connector loosening
- No special tools required for installation or removal
- Fully interchangeable with 3300 XL extension cables and proximitor sensors
Application Scenarios:
- Shaft vibration monitoring on fluid-film bearing machines
- Shaft position (displacement) measurement
- Keyphasor and speed measurement
- Applications where 8mm probes cannot fit due to space constraints
- General rotating machinery condition monitoring
Performance Parameters:
- Sensitivity: 7.87 V/mm (200 mV/mil)
- Linear Range: 2mm (80 mils)
- Frequency Response: 0 to 10 kHz
- Supply Voltage: -17.5 VDC to -26 VDC
- Operating Temperature: -40°C to +85°C (standard probe)
Material Composition:
- Probe Tip: PPS (Polyphenylene Sulfide)
- Probe Housing: Stainless steel
- Cable: FEP (Fluoroethylene Propylene) insulated 75Ω coaxial cable
- Connectors: Gold-plated brass ClickLoc
Structural Features:
- Cylindrical 5mm probe body with sensing face at front end
- 1/4-28 UNF imperial thread for mounting
- 1.0-meter integral cable with ClickLoc connector
- Non-armored design
- Connector protector available as option
Working Principle: The 5mm probe operates on the eddy current principle. High-frequency current through the internal coil generates an alternating magnetic field. When a conductive target surface enters this field, eddy currents are induced, altering the coil impedance. The proximitor converts this impedance change into a voltage signal proportional to the gap distance. The system measures both static (position) and dynamic (vibration) data.
Installation Requirements:
- The mounting hole must be pre-machined with 1/4-28 UNF internal thread
- Total system length (probe cable + extension cable) must match the proximitor’s nominal length (5-meter or 9-meter)
- ClickLoc connectors require only finger-tight torque (connectors will “click”)
- Connector protectors are recommended for all installations
- Probe axis must be aligned perpendicular to the target surface
Usage Precautions:
- The unthreaded length must be at least 0.8 inches less than the case length
- Cable bending radius must meet minimum requirements
- Shield must be grounded at a single point only
- Verify probe RPROBE after installation to confirm cable integrity
- Use proper grounding and routing to avoid EMI coupling
