Description
Bently Nevada 330905-00-10-10-02-05
Technical Specifications
| Parameter | Specification |
|---|---|
| Part Number | 330905-00-10-10-02-05 |
| Thread Type | M10 x 1 |
| Armor Option | Without armor |
| Unthreaded Length | 0.0 inch |
| Overall Case Length | 1.0 inch |
| Total Cable Length | 1.0 meter (3.3 feet) |
| Connector Type | Miniature coaxial ClickLoc connector, standard cable |
| Agency Approval | Multiple Approvals (CE, UL, CSA) |
| Probe Tip Diameter | 5 mm (0.20 in) |
| Sensitivity | 7.87 V/mm (200 mV/mil) |
| Linear Range | 1.5 mm (60 mils) |
| Frequency Response | 0 to 10 kHz |
| Operating Temperature | -35°C to +177°C (-31°F to +350°F) |
Functional Features The probe features superior side-view characteristics for installation in confined spaces. The 5 mm tip diameter enables measurement on small targets such as shafts smaller than 51 mm. The multiple agency approval option ensures compliance with international safety standards for hazardous and non-hazardous installations. The ClickLoc connector provides secure, vibration-resistant connection. The probe is fully interchangeable with other 3300 XL NSv components.
Application Scenarios Hazardous area compressor monitoring, regulated industry refrigeration equipment, oil and gas process gas compressor monitoring, petrochemical pump monitoring, offshore platform small machinery monitoring, chemical processing equipment, global industrial facilities requiring agency approvals.
Performance Parameters The probe delivers 7.87 V/mm sensitivity with linearity within system specifications. The multiple agency approvals cover intrinsically safe and non-incendive installations according to ATEX, IECEx, and CSA standards. The 1.0 meter cable maintains stable electrical characteristics across the full temperature range.
Material Composition Probe tip is polyphenylene sulfide (PPS). Probe case is AISI 304 stainless steel. Cable is 75 Ω triaxial with FEP insulation. Connector material is gold-plated brass.
Structural Characteristics The probe features M10 x 1 metric thread with a 1.0 inch case length. The 0.0 inch unthreaded length positions the thread adjacent to the probe shoulder. The non-armored cable has a standard outside diameter. The probe is marked with part number and agency approval information.
Working Principle The probe generates a high-frequency electromagnetic field at the 5 mm probe tip. Eddy currents induced in the conductive target surface modify the RF field. The Proximitor Sensor detects these modifications and outputs a DC voltage proportional to the gap distance.
