Description
Bently Nevada 330905-00-15-10-02-00
Technical Specifications
| Parameter | Specification |
|---|---|
| Part Number | 330905-00-15-10-02-00 |
| Thread Type | M10 x 1 |
| Armor Option | Without armor |
| Unthreaded Length | 0.0 inch |
| Overall Case Length | 1.5 inch |
| Total Cable Length | 1.0 meter (3.3 feet) |
| Connector Type | Miniature coaxial ClickLoc connector, standard cable |
| Agency Approval | Not required |
| Probe Tip Diameter | 5 mm (0.20 in) |
| Sensitivity | 7.87 V/mm (200 mV/mil) |
| Linear Range | 1.5 mm (60 mils) |
| Frequency Response | 0 to 10 kHz |
| Operating Temperature | -35°C to +177°C (-31°F to +350°F) |
Functional Features The 1.5 inch case length provides increased thread engagement for secure mounting in thicker housings. The M10 x 1 metric thread offers robust mounting strength. The NSv design provides superior side-view characteristics for confined installations. The 5 mm tip diameter enables small target measurement. The probe is fully interchangeable with other 3300 XL NSv components.
Application Scenarios Compressor monitoring with thick mounting plates, pump vibration measurement through extended adapters, small turbine installations requiring deeper probe penetration, generator monitoring in moderately thick housings, industrial fan bearing monitoring, machinery with deep M10 threaded mounting holes.
Performance Parameters The probe delivers 7.87 V/mm sensitivity with linearity within system specifications over the 1.5 mm range. The extended case adds approximately 1.1 g per mm to the probe weight. The 1.0 meter cable maintains stable electrical characteristics. The system maintains full interchangeability without recalibration.
Material Composition Probe tip is polyphenylene sulfide (PPS). Probe case is AISI 304 stainless steel. Cable is 75 Ω triaxial with FEP insulation. Connector material is gold-plated brass.
Structural Characteristics The probe features M10 x 1 metric thread with a 1.5 inch case length. The 0.0 inch unthreaded length means the thread extends to the probe shoulder. The non-armored cable has a standard outside diameter for flexible routing. The ClickLoc connector provides secure locking engagement.
Working Principle The probe generates a high-frequency electromagnetic field at the 5 mm probe tip. Eddy currents induced in the conductive target surface modify the RF field characteristics. The Proximitor Sensor measures these modifications and outputs a DC voltage proportional to the gap distance.
