Bently Nevada 330905-00-15-10-02-05
Technical Specifications
- Base Model: 330905, 3300 NSv Probe with M10×1 thread, without armor
- Unthreaded Length: 0 mm (fully threaded)
- Overall Case Length: 150 mm
- Total Probe Length: 1.0 meter (39 inches)
- Connector Type: Miniature coaxial ClickLoc connector, standard cable
- Agency Approval: Multiple approvals including ATEX, IECEx, CSA
- Linear Range: 1.5 mm (60 mils) from 0.25 mm to 1.75 mm
- Scale Factor: 7.87 V/mm (200 mV/mil)
- Frequency Response: 0 to 10 kHz (+0, -3 dB)
- Probe Tip Diameter: 5 mm
- Probe Case Material: AISI 304 stainless steel
- Probe Tip Material: Polyphenylene sulfide
- Operating Temperature: -52°C to +177°C
- Storage Temperature: -52°C to +177°C
- DC Resistance: 4.2 ± 0.5 Ω
- Minimum Bend Radius: 25.4 mm
Functional Features
- Narrow Side-view design for tight clearance installations
- Enhanced side-view characteristics compared to standard 5 mm and 8 mm probes
- Suitable for small target applications including shafts under 51 mm diameter
- Fully compatible with 3300 XL NSv Proximitor sensors and extension cables
- Patented TipLoc molding provides robust bond between probe tip and body
- Gold-plated brass ClickLoc connectors lock into place preventing loosening
- Complete system interchangeability without field recalibration
Application Scenarios
- Centrifugal compressor radial vibration monitoring
- Refrigeration compressor bearing position measurement
- Process gas compressor shaft displacement tracking
- Small steam turbine rotor dynamics analysis
- High-speed pump and motor vibration surveillance
Performance Parameters
- Linearity Deviation: Less than ±0.06 mm from best fit straight line
- Resolution: Sub-micron vibration detection capability
- Interchangeability Error: Within ±10% when used with Bently Nevada target
- Temperature Stability: Sensitivity maintained within ±10% over full range
- Maximum Thread Engagement: 15 mm
- Recommended Probe Torque: 11.3 N·m (100 in·lb)
- Maximum Torque: 33.9 N·m (300 in·lb)
Material Composition
- Probe Case: AISI 304 stainless steel
- Probe Tip: Polyphenylene sulfide
- Cable Insulation: Fluorinated ethylene propylene
- Cable Shield: Tinned copper braid
- Connector Contacts: Gold-plated brass
- Connector Body: Nickel-plated brass or stainless steel
- O-ring Seal: Fluorocarbon elastomer
Structural Characteristics
- Cylindrical probe body with M10×1 external thread
- Fully threaded case length of 150 mm
- Integral 1.0 meter coaxial cable exiting from probe rear
- Miniature coaxial ClickLoc connector with positive locking mechanism
- Smooth PPS probe tip face for consistent electromagnetic field distribution
Working Principle The probe contains a precision-wound coil that, when excited by the Proximitor sensor’s RF signal, generates an alternating electromagnetic field at the probe tip. When a conductive metal target enters this field, eddy currents are induced in the target surface. These eddy currents draw energy from the coil, altering its impedance in proportion to the gap distance. The Proximitor sensor detects this impedance change and converts it into a linear voltage output proportional to the physical gap between probe tip and target.
Installation Requirements
- Mount in M10×1 threaded hole perpendicular to target surface
- Ensure maximum thread engagement does not exceed 15 mm
- Set initial probe gap to 1.0 mm (40 mils) for center of linear range
- Verify gap voltage of approximately -10 Vdc after installation
- Route cable away from high-current power conductors
- Maintain minimum bend radius of 25.4 mm
Usage Precautions
- Do not exceed maximum torque of 33.9 N·m during installation
- Verify target material is ferromagnetic steel for standard calibration
- Maintain minimum distance of 3 probe diameters from surrounding metal objects
- Inspect ClickLoc connector for secure mechanical latching after mating
- Replace O-ring seals during major overhauls to maintain pressure integrity
- Do not use with standard 3300 XL Proximitor; NSv-specific components required
