Bently Nevada 3500/05-01-02-00

Bently Nevada 3500/05-01-02-00

Product Overview: The 3500/05-01-02-00 is a full-size 19-inch EIA system rack within the Bently Nevada 3500 Machinery Protection System. It provides the mechanical enclosure, backplane bus, and power distribution infrastructure for all 3500 monitor modules, power supplies, and interface modules. The part number decoding is as follows: “01” designates the full-size 19-inch EIA rack with 14 available module slots; “02” designates the rack-mount installation option (mounted on a standard 19-inch EIA rail). Wiring connections and I/O modules are accessed from the rear of the rack.

Request Quote
Category:

Description

Bently Nevada 3500/05-01-02-00

Technical Specifications:

  • Rack Size: Full-size, 19-inch EIA
  • Module Slots: 14 available slots
  • Mounting Option: Rack-mount (installed on 19-inch EIA rail)
  • Backplane Communication: Provides inter-module communication bus for all installed 3500 modules
  • Power Distribution: Distributes power from 3500/15 power supply modules to all installed modules
  • Compliance: FCC Part 15, EMC Directive 2014/30/EU (EN 61000-6-2), Low Voltage Directive 2014/35/EU (EN 61010-1), RoHS Directive 2011/65/EU

Functional Features:

  • Modular design allows easy addition or removal of modules to meet varying application requirements
  • Backplane bus enables inter-module communication without external wiring
  • Supports redundant power supply configuration for enhanced system reliability
  • Compatible with System1 software for module configuration and monitoring
  • Multiple installation format options available across the 3500/05 product family

Application Scenarios:

  • Turbine Supervisory Instrumentation (TSI) systems in power generation
  • Machinery protection systems in petrochemical and refining plants
  • Compressor, pump, and fan monitoring in oil and gas processing
  • Industrial process control environments requiring API 670-compliant monitoring

Performance Parameters:

  • Slot capacity: 14 full-height module positions
  • Backplane data bus supports real-time inter-module communication
  • Supports dual redundant 3500/15 power supplies
  • Environmental ratings consistent with 3500 system specifications

Material Composition:

  • Sheet metal enclosure with industrial-grade finish
  • Internal backplane PCB with gold-plated edge connectors
  • Front and rear panel assemblies with module guide rails

Structural Features:

  • 19-inch EIA standard form factor
  • Rear-access wiring and I/O connections
  • Module guide rails for plug-in installation of all 3500 modules
  • Cable management provisions at the rear

Working Principle:
The rack serves as the mechanical and electrical backbone of the 3500 system. The backplane provides power distribution from the 3500/15 power supply modules to all installed modules and establishes a shared communication bus that allows modules to exchange data, synchronize alarm states, and coordinate protection actions without external wiring.

Installation Requirements:

  • Mount on a standard 19-inch EIA rail using the provided mounting hardware
  • Ensure adequate clearance at the rear for wiring access and module extraction
  • Install the 3500/15 power supply and 3500/20 Rack Interface Module in the leftmost two slots
  • Ground the rack according to Bently Nevada grounding practices
  • If internal partitions are installed, a 3500/04-01 internal partition grounding module is required in a dedicated rack position

Usage Notes:

  • The rack-mount format provides rear access only — ensure the installation location allows rear access for wiring and maintenance
  • The 3500/05 mini-rack does not support the wall-mount option; this full-size rack supports panel-mount, rack-mount, and wall-mount formats
  • When using the mini-rack in a 19-inch EIA rack, a 144863-01 adapter panel is required (not applicable to this full-size model)
  • Verify that the rack is properly grounded before energizing any modules
