Bently Nevada 3500/42-02-00
Technical Specifications:
- Module Type: Full-height, 4-channel configurable monitor
- Input Signal Range: -10V DC to +10V DC
- Power Consumption: 7.7 watts typical
- Sensor Power Supply: -24V DC
- Resolution: Up to 24-bit
- Frequency Response: Up to 1 kHz (60,000 cpm)
- Operating Temperature: -30°C to +65°C (-22°F to +150°F)
- Storage Temperature: -40°C to +85°C (-40°F to +185°F)
- Humidity: 95% non-condensing
- Agency Approval: None
Functional Features:
- Identical measurement and processing capabilities to the 3500/42-01-01
- Configurable for radial vibration, axial position, differential expansion, eccentricity, acceleration, velocity, and absolute shaft vibration
- Channels programmed in pairs
- Differential signal processing for absolute shaft vibration measurement
- Built-in automatic calibration
- Up to 24-bit resolution
- External termination I/O module for field wiring connections at a separate terminal block
Application Scenarios:
- Applications where CSA/NRTL/C agency approval is not required
- Installations where field wiring is routed through external terminal blocks
- Steam turbine, compressor, pump, fan, and generator vibration monitoring
- Power generation, petrochemical, and metallurgical industries
Performance Parameters:
- Channel count: 4 channels per module (programmed in pairs)
- Measurement accuracy: ±0.5% full scale
- Vibration measurement range: 0–1000 μm peak-to-peak
- Displacement measurement range: 0–2000 μm
- Frequency response: 0.5–1000 Hz (vibration), 0–100 Hz (displacement)
Material Composition:
- High-reliability electronic components on multi-layer PCB
- Metal module enclosure with conformal coating
- Gold-plated backplane edge connectors
Structural Features:
- Full-height module form factor
- Front panel with OK, TX/RX, and Bypass LED indicators
- Rear I/O module with external terminal connections (field wiring connected at separate terminal block)
- Plug-in design compatible with any accessible rack slot
Working Principle:
Identical to the 3500/42-01-01 — receives analog signals from sensors, conditions and processes them according to the programmed measurement function, compares against alarm setpoints, and drives alarm and analog outputs accordingly.
Installation Requirements:
- Install the main module in any accessible full-height rack slot
- Install the corresponding external termination I/O module in the rear slot
- Connect sensor cables to the external terminal
