Description
B&R 8LSA46.R0045D000
Technical Specifications:
- Brand: B&R Industrial Automation
- Model: 8LSA46.R0045D000
- Product Type: Synchronous Motor
- Rated Speed: 2200 to 6000 rpm
- Stall Torque: 4 to 10 Nm
- Flange Size: 100 x 100 mm
Functional Features:
- High Power Density: Delivers maximum torque output relative to its compact footprint.
- Broad Speed Range: Operates efficiently across a wide speed range from 2200 to 6000 rpm.
- Universal Applicability: Engineered with high overload capacity to handle variable and demanding load profiles.
- Cost Efficiency: Simplified structure and easy maintenance reduce total cost of ownership.
Application Scenarios:
Perfect for heavy-duty conveyors, extruders, centrifuges, and large robotic arms requiring high continuous and peak torque.
Performance Parameters:
- Center Diameter: 95j6 mm
- Shaft Diameter: 19k6 mm (with reinforced bearing option: 24k6 mm)
- Torque Ripple: Highly optimized for smooth and precise motion control.
Material Composition:
Features reinforced bearing options and high-grade internal components to withstand high mechanical stress and continuous industrial operation.
Structural Characteristics:
Utilizes a 100 x 100 mm flange with a robust mechanical design. Supports various cooling types and connector options to adapt to specific machine layouts.
Working Principle:
Generates high torque through advanced electromagnetic design and precise rotor-stator alignment, controlled by B&R servo drives for optimal dynamic performance.
Installation Requirements:
Securely fasten to the machine frame using the 100 x 100 mm flange. Utilize the reinforced 24k6 mm shaft option if the application involves high radial loads.
Usage Precautions:
Verify the shaft diameter and bearing specifications match the mechanical load requirements. Ensure the drive is properly tuned to the embedded parameter chip.
