Description
B&R 8V1016.00-2
Technical Specifications:
- Brand: B&R Industrial Automation
- Model: 8V1016.00-2
- Product Type: Industrial Servo Drive
- Series: ACOPOS
Functional Features:
- Advanced Control Algorithms: Features state-of-the-art current, speed, and position control loops for ultra-smooth motion.
- High Overload Capacity: Delivers peak current for rapid acceleration and transient load handling.
- Integrated Safety: Supports safe torque off (STO) and other safety functions for machine compliance.
- Seamless Integration: Natively integrates with B&R PLCs and motion controllers via POWERLINK.
Application Scenarios:
Used in virtually all B&R motion control applications, including packaging, robotics, CNC, and printing presses.
Performance Parameters:
- Dynamic Response: Microsecond-level current loop update rates.
- Positioning Accuracy: Sub-micron positioning precision when paired with high-resolution encoders.
Material Composition:
Industrial-grade power electronics, high-efficiency IGBTs, and robust thermal management components housed in a compact enclosure.
Structural Characteristics:
Compact, bookshelf-style design with plug-in power and signal connectors. Features intuitive LED status indicators and diagnostic ports.
Working Principle:
Receives motion commands from the controller, processes encoder feedback, and generates precise PWM signals to drive the connected servo motor with exact torque and speed.
Installation Requirements:
Mount vertically with adequate clearance for cooling airflow. Connect motor and encoder cables using shielded B&R-specific connectors.
Usage Precautions:
Ensure proper grounding of the drive and motor. Never disconnect motor cables while the drive is energized to prevent damage to the power stage.
