Product Introduction: The 100-40-050-P1-45-S1-B0 is a specific configuration of the SM100 series servo motor. It is designed for high-precision motion control applications, offering a balance of speed and torque.

Request Quote
Category:

Description

ELAU 100-40-050-P1-45-S1-B0

Technical Specifications:

  • Brand: ELAU (Schneider Electric)
  • Model: 100-40-050-P1-45-S1-B0
  • Series: SM100
  • Flange Size: 100 mm
  • Brake: No Brake (B0)

Functional Features:

  • High Precision: Supports high-precision motion control.
  • Robust Design: IP65 protection for harsh environments.
  • Modular Integration: Compatible with ELAU PacDrive systems.
  • High Dynamic Response: Low inertia design for fast acceleration.

Application Scenarios:

  • Packaging machinery (capping, labeling).
  • Robotics.
  • CNC machine tools.

Performance Parameters:

  • Rated Speed: 4000 RPM.
  • Rated Torque: 5.0 Nm.
  • Control Precision: High precision positioning.

Material Composition:

  • Industrial metal housing.
  • High-grade electronic components.

Structural Features:

  • Flange mounting.
  • Robust housing for industrial environments.

Working Principle:
The motor utilizes a permanent magnet rotor and a stator with three-phase windings. The drive controls the current to generate a rotating magnetic field, driving the rotor. Feedback from the encoder ensures accurate closed-loop control.

Installation Requirements:

  • Mount on a standard industrial flange.
  • Ensure adequate ventilation.
  • Connect shielding cables properly to minimize EMI.

Usage Notes:

  • Verify the voltage rating matches the power supply.
  • Ensure the connected drive is compatible with the motor’s current rating.
  • Do not exceed the maximum permissible loads on the shaft.
