ELAU MC-4-11-10-400-00

ELAU MC-4-11-10-400-00

Product Introduction: The ELAU MC-4-11-10-400-00 is a high-performance servo drive from the PacDrive series. It integrates the power supply, output stage, and software regulator into a single compact housing, ideal for decentralized structures.

Request Quote
Category:

Description

ELAU MC-4-11-10-400-00

Technical Specifications:

  • Brand: ELAU (Schneider Electric)
  • Model: MC-4-11-10-400-00
  • Product Type: Servo Drive
  • Rated Voltage: 3-phase AC 380-480V
  • Rated Current: 10A
  • Peak Current: 25A
  • Control Voltage: DC 24V
  • Protection Class: IP20

Functional Features:

  • Integrated Design: Power, drive, and control in one unit.
  • Communication: Supports SERCOS, EtherCAT, CANopen.
  • Control Modes: Position, Speed, and Torque control.
  • Overload Capacity: Supports 250% short-term overload.

Application Scenarios:

  • Robotics.
  • Packaging machinery.
  • CNC machine tools.
  • Printing equipment.

Performance Parameters:

  • Power: 6.9 kVA (approx).
  • Control Precision: Micrometer level.
  • Response Time: Millisecond range.

Material Composition:

  • Ruggedized industrial housing.
  • High-quality PCB.

Structural Features:

  • Wall mount or DIN rail.
  • Fiber optic interface for controller communication.

Working Principle:
The drive receives setpoints from the controller via fieldbus, calculates the required current, and drives the motor windings to achieve precise motion.

Installation Requirements:

  • Ensure proper grounding.
  • Use shielded motor cables.
  • Provide sufficient cooling.

Usage Notes:

  • This model requires a license for full operation.
  • Verify the firmware version.
