Description
Emerson 1C31166G02
Technical Specifications:
- Brand: Emerson
- Model: 1C31166G02
- Product Type: Signal Conditioning Module
Functional Features:
- Galvanic Isolation: Provides high-voltage isolation between field inputs and system outputs to protect against ground loops and surges.
- High-Accuracy Linearization: Corrects non-linearities from field sensors to deliver precise data to the control system.
- Noise Immunity: Advanced analog filtering rejects electromagnetic interference and radio frequency interference.
Application Scenarios:
Used in environments with high electrical noise or where long cable runs require signal boosting and protection, such as steel mills and power plants.
Performance Parameters:
- Signal Fidelity: Extremely low total harmonic distortion and temperature drift.
- Response Time: Fast signal processing to support high-speed control loops.
Material Composition:
Features flame-retardant housing and gold-plated contact points for reliable electrical connections over the module’s lifecycle.
Structural Characteristics:
Slim profile design maximizes panel space utilization. Includes clear, laser-etched terminal markings for error-free wiring.
Working Principle:
Receives raw analog signals, applies galvanic isolation, scales the signal to standard ranges, and outputs a clean, isolated signal to the DCS input card.
Installation Requirements:
Ensure proper grounding of the isolation barrier. Use twisted-pair shielded cables for all field connections.
Usage Precautions:
Verify input signal ranges match the module configuration before energizing. Avoid exposing the module to excessive ambient temperatures.
