Emerson 1C31224G01
Technical Specifications:
- Brand: Emerson (Ovation)
- Model: 1C31224G01
- Product Type: 4-20mA Analog Input EMOD
- Input Signal: 4-20mA DC
Functional Features:
- High Accuracy: Precision current-to-digital conversion for reliable process monitoring.
- Loop Power: Provides field transmitter loop power (2-wire transmitter support).
- Diagnostics: Detects open loops, short circuits, and out-of-range conditions.
Application Scenarios:
Universal analog signal acquisition for temperature, pressure, level, and flow transmitters across all process industries.
Performance Parameters:
- Input Impedance: Low impedance to minimize loop voltage drop
- Conversion Rate: High-speed sampling for dynamic processes
Material Composition:
Precision analog components with high noise immunity.
Structural Characteristics:
Compact EMOD form factor with clear channel labeling.
Working Principle:
Measures the 4-20mA current loop, converts it to a digital value via an ADC, and scales it to engineering units for the controller.
Installation Requirements:
Wire 2-wire transmitters with correct polarity. Use shielded cable and ground at the panel.
Usage Precautions:
Ensure loop power supply capacity is sufficient for all connected transmitters. Configure scaling parameters correctly in the Ovation software.
