Description
Emerson IC200pwr001
Technical Specifications
- Input Voltage: 24VDC
- Output Power: Supply power for VersaMax rack CPU and I/O modules
- Operating Ambient Temperature: 0℃ ~ 60℃
- Storage Temperature: -40℃ ~ 85℃
- Relative Humidity: 5% ~ 95%, non-condensing
- Mounting Mode: DIN rail installation or rack plug-in installation
- Built-in overvoltage, undervoltage and overcurrent protection circuit
- Front panel power status LED indicator
Functional Features DC-DC conversion circuit provides stable regulated power supply for each module on VersaMax rack. Hardware protection circuit cuts off output automatically when overvoltage, undervoltage or overcurrent fault occurs. Front panel LED indicator displays power normal or fault state. Compact mechanical structure supports quick installation on DIN rail. It can be installed at leftmost position of VersaMax PLC rack to supply power for all subsequent I/O modules.
Application Scenarios VersaMax PLC automation cabinets for machinery manufacturing, water treatment, packaging equipment and small chemical auxiliary control systems. It serves as rack power source for VersaMax CPU and digital / analog I/O modules.
Performance Parameters DC-DC conversion maintains stable output voltage under rated full load in whole working temperature range. Protection circuit responds rapidly once electrical parameters exceed safe threshold. Low output ripple reduces interference to PLC logic and signal acquisition circuit.
Material Composition Flame-retardant engineering plastic housing. Multi-layer flame-retardant glass fiber epoxy PCB. DC-DC conversion chips, filter capacitors, power switching devices and sampling circuit components. LED status indicator. Metal DIN rail buckle and copper alloy terminal connectors.
Structural Features Compact rectangular module structure. Front panel with power status LED indicator. Terminal blocks at one side for 24VDC power input wiring. Rear DIN rail buckle for cabinet installation. Side bus connector transmits power to adjacent PLC modules.
Working Principle External 24VDC power connects to module input terminals. Internal DC-DC conversion circuit stabilizes voltage and outputs regulated DC power. Power transmits through side internal bus to VersaMax CPU and all I/O modules on rack. Sampling circuit continuously monitors output voltage and output current. When abnormal electrical parameters are detected, hardware protection circuit activates and LED fault indication triggers.
Installation Requirements Install module on standard DIN rail inside control cabinet and lock mounting buckle. Connect 24VDC power cable to input terminals and fasten terminal screws. Install module at the leftmost position of VersaMax rack to supply power for whole rack. Reserve ventilation space around module for heat dissipation.
Precautions for Use Cut off external 24VDC power before wiring operation. Check input power polarity before power on. Do not cover module ventilation area. Inspect terminal tightness regularly. Do not disassemble module plastic housing.
