Description
Emerson KJ1700X1-BA1
Technical Specifications
- Communication Protocol: PROFIBUS DP
- Communication Speed: Supports multiple baud rate options
- LocalBus Supply: 12VDC
- Isolation: Galvanic isolation between PROFIBUS DP bus and DCS backplane
- Operating Ambient Temperature: 0℃ ~ 60℃
- Storage Temperature: -40℃ ~ 85℃
- Relative Humidity: 5% ~ 95%, non-condensing
- Protection Grade: IP20
- Installation Type: DeltaV rack plug-in module
- Built-in PROFIBUS DP bus communication fault diagnosis function
- Front panel LED indicators for module and bus status
Functional Features High-speed PROFIBUS transceiver circuit realizes bidirectional data exchange between DeltaV controller and PROFIBUS DP slave devices. Real-time bus monitoring circuit detects bus disconnection, signal attenuation and slave offline state. Front-panel LED indicators display module running status and PROFIBUS DP bus communication state. Plug-in rack mechanical design supports hot swap under non-critical process operating conditions. Built-in surge protection circuit suppresses interference on PROFIBUS DP communication bus.
Application Scenarios DeltaV DCS main control cabinets in chemical plants, oil refineries and pulp and paper mills. It serves as communication bridge between DeltaV main controller and PROFIBUS DP field devices such as frequency converters and remote I/O stations.
Performance Parameters Communication circuit maintains stable high-speed data transmission within full working temperature range. Diagnostic circuit captures PROFIBUS DP bus communication abnormality rapidly. Bus interface withstands electromagnetic interference from industrial field environment. Data transmission keeps low packet loss rate under continuous long-time operation.
Material Composition Flame-retardant engineering plastic front panel. Multi-layer flame-retardant glass-fiber epoxy PCB. Communication processing microprocessor, PROFIBUS transceiver chips and LED indicators. Gold-plated copper alloy backplane connector. Metal shielding components for anti-electromagnetic interference.
Structural Features Standard plug-in card matching DeltaV rack slot. Front panel equipped with running status LED and bus fault LED indicators. Guide rails and mechanical latch lock module firmly inside rack. Rear gold-plated connector mates with DeltaV rack backplane. External PROFIBUS DP terminal ports for field bus cable connection. Internal metal shielding reduces electromagnetic interference impact.
Working Principle The module connects to DeltaV controller through rack backplane and connects to PROFIBUS DP slave devices via PROFIBUS shielded twisted-pair cables. It receives control instructions from DeltaV controller and forwards instructions to corresponding PROFIBUS DP slave devices. It collects field process data and diagnostic information uploaded by slave devices and transmits data back to DeltaV controller. On-board monitoring circuit checks bus signal quality and slave device online status continuously. When communication failure or slave offline occurs, module generates fault alarm and sends alarm message to DeltaV operator station.
Installation Requirements Insert module along rack guide rail into designated DeltaV rack slot and lock mechanical latch. Use PROFIBUS standard shielded twisted-pair cables for field wiring. Terminate bus terminals at both ends of PROFIBUS segment. Separate PROFIBUS bus cables from high-voltage power cables. Reserve air circulation space around module for heat dissipation. Complete PROFIBUS DP bus parameter configuration and slave device assignment in DeltaV engineering workstation after hardware installation.
Precautions for Use Take anti-static protective measures during module handling. Do not touch gold-plated connector pins directly by bare hands. Inspect PROFIBUS cable, bus terminal resistor and connector condition regularly. Do not apply overvoltage to PROFIBUS communication terminals. Do not disassemble module housing.
