Description
Emerson MVME61006E-0163
Technical Specifications
- Form factor: VME64 single board computer
- Processor: High-performance PowerPC processor
- Onboard memory: Pre-installed RAM and flash storage
- Interfaces: Ethernet port, serial port, VME bus interface
- Operating ambient temperature: 0℃ ~ 60℃
- Storage temperature: -40℃ ~ 85℃
- Relative humidity: 5% ~ 95%, non-condensing
- Support VME64 bus communication
Functional Features High-performance embedded processor executes real-time application program and industrial data processing. Onboard flash memory stores operating system and application firmware. Multiple communication interfaces realize network data exchange and serial device connection. VME bus interface supports data communication with other VME board modules in chassis. Hardware watchdog circuit monitors processor running state and triggers automatic reset upon program failure. Front panel status LED indicators show power, running and fault state.
Application Scenarios Industrial VME chassis systems used in power generation, transportation and heavy industry, applied for embedded data acquisition, legacy control system host, equipment condition monitoring gateway.
Performance Parameters
- Processor delivers stable real-time computing capability for industrial embedded tasks
- Onboard memory maintains reliable data storage under industrial temperature range
- Hardware watchdog responds reliably to processor abnormal operation
- VME bus communication maintains high throughput for data exchange between VME boards
Material Composition Multi-layer high-density flame-retardant glass fiber epoxy PCB. PowerPC processor chip, memory chips, flash storage chips, Ethernet controller, VME bus controller and watchdog circuit. Gold-plated VME edge connector. Metal front panel with anti-corrosion coating and status LED indicators.
Structural Features Standard 6U VME single board form factor. Metal front panel mounted with LED indicators and external communication connectors. Edge gold-plated connector at board rear inserts into VME chassis backplane. Board surface has fixing holes for chassis mechanical fastening. Layout reserves airflow path for component cooling.
Working Principle After power-on, the board loads embedded operating system from onboard flash memory and starts application program. The processor collects data through VME bus from other VME modules. It processes data locally and exchanges information with external devices via Ethernet and serial ports. Hardware watchdog circuit continuously monitors processor heartbeat signal. If heartbeat stops due to program crash, watchdog triggers hardware reset to restart the single board computer.
Installation Requirements Insert the board into 6U VME chassis slot and fasten front panel fixing screws. Ensure chassis protective earth connects to ground bus. Route external communication cables separately from high-power cables. Reserve chassis fan cooling airflow for the board. Complete firmware configuration after hardware installation.
Precautions for Use Power off VME chassis before board insertion or removal. Take anti-static protection when handling the board to prevent electrostatic damage to chips. Backup firmware and application program before replacement. Do not touch gold-plated edge connector directly. Keep chassis fan and filter clean to maintain cooling performance.
