Foxboro P0916WF
Technical Specifications
- Hardware Code: P0916WF.
- Bus Interface: Foxboro Module Fieldbus.
- Power: 24 VDC backplane supply.
- Form Factor: Single-width 200 Series FBM.
Functional Features
- Native Compatibility: Directly mounts on 200 Series baseplates for seamless integration.
- Hot-Swappable Maintenance: Supports online replacement to minimize downtime.
- Redundancy Ready: Architecture supports redundant I/A nodes for high availability.
- Integrated Diagnostics: Built-in status LEDs and health reporting simplify inspections.
Application Scenarios
Deployed in upstream oil and gas wellheads, gas compression stations, refinery unit balancing, and utility systems.
Performance Parameters
- Operating Temperature: 0°C to 60°C.
- Protection: Conformal-coated electronics for dust and moisture resistance.
Material Composition
Compact single-width enclosure with industrial-grade conformal coating on internal PCBs.
Structural Characteristics
- Dimensions: Standard 200 Series FBM size.
- Termination: Interfaces via designated Foxboro Termination Assemblies (TA).
Working Principle
Acquires signals from the field TA, digitizes them, and uploads data via the backplane fieldbus while receiving and executing downstream controller commands.
Installation Requirements
- Must be installed in a clean, well-ventilated control cabinet.
- Ensure backplane connectors are fully aligned and locked.
- Field wires must be correctly terminated on the matching TA.
Precautions for Use
- Always verify the P0916WF hardware code before replacement.
- Maintain low-impedance protective grounding for noise immunity.
- Observe strict ESD precautions during maintenance.
