Description
Foxboro 6GT2001-0AA00 Technical Specifications:
- Product Family: SIMATIC RF200 (RF260R).
- Communication Interface: RS-232 interface utilizing the 3964R protocol.
- Protection Class: IP67 rated for complete dust protection and resistance to water jets.
- Temperature Range: Rated for operation in extreme environments from -25°C to +70°C.
- Dimensions: Compact form factor measuring 75 x 75 x 40 mm.
- Antenna: Integrated antenna design.
Functional Features:
- Contactless Data Transfer: Reads and writes data to RFID tags without physical contact or line-of-sight requirements.
- Robust Protocol: Utilizes the 3964R protocol for reliable, error-checked serial data transmission to PLCs or PCs.
- Harsh Environment Ready: The IP67 rating and wide temperature tolerance make it suitable for washdown areas and unheated outdoor facilities.
- Plug-and-Play: Designed for easy integration into existing Siemens automation architectures.
Application Scenarios:
- Tool and pallet identification on automated assembly lines.
- Work-in-progress (WIP) tracking in automotive manufacturing.
- Intralogistics and conveyor system sorting.
- Traceability and batch management in food processing and packaging.
Performance Parameters:
- Read/Write Range: Optimized for short to medium-range UHF/HF transponder communication (depending on tag type).
- Data Transfer Rate: High-speed serial communication for rapid tag reading on fast-moving conveyors.
- Durability: High mechanical shock and vibration resistance for industrial mounting.
Material Composition & Structural Characteristics:
- Housing: Rugged, high-impact plastic enclosure with sealed gaskets to achieve the IP67 rating.
- Antenna: Fully integrated and encapsulated within the housing to prevent physical damage.
- Connectors: Industrial-grade circular or heavy-duty serial connectors with secure locking mechanisms.
- Internal Electronics: Shielded PCB to protect against electromagnetic interference from nearby motors and drives.
Working Principle: The reader generates an electromagnetic field via its integrated antenna. When an RFID transponder enters this field, it is energized and transmits its stored data back to the reader. The RF260R demodulates this signal, processes the data using the 3964R protocol, and sends it via the RS-232 interface to the host controller. It can also receive write commands from the host to update the transponder’s memory.
Installation Requirements:
- Mounting: Securely mount the reader using appropriate brackets, ensuring the read face is unobstructed.
- Wiring: Use shielded RS-232 cables and connect them according to the pinout diagram to prevent signal degradation.
- Clearance: Maintain adequate clearance from large metal surfaces to prevent detuning of the integrated antenna.
- Power Supply: Connect to a stable 24V DC power supply with appropriate fusing.
Usage Precautions:
- Metal Interference: Be aware that nearby metal can reduce the read range; perform site surveys to optimize tag placement.
- Cable Routing: Route communication cables away from high-voltage power lines to avoid electromagnetic interference.
- Transponder Compatibility: Ensure the RFID tags used are fully compatible with the RF260R frequency and protocol.
- Maintenance: Periodically clean the reader face to remove dirt, grease, or metallic shavings that could impede performance.
