Description
GE IC697PWR710H
Technical Specifications:
- Input Voltage: Typically 120/240V AC or 125V DC (confirm exact range in datasheet)
- Output Voltages: +5V DC and other required backplane voltages
- Output Current: High-current capability (check datasheet for exact ratings)
- Protection: Overvoltage, overcurrent, and short-circuit protection
- Indicators: LEDs for power status and fault indication
- Operating Temperature: 0°C to 60°C
- Humidity: 5% to 95% non-condensing
Functional Features:
- Delivers stable and regulated power to all modules in the rack.
- Includes comprehensive protection features to safeguard the system.
- Designed for high reliability and long life in industrial settings.
Application Scenarios:
- Powering large Series 90-70 racks with numerous modules.
- Systems with high I/O count and demanding power requirements.
Performance Parameters:
- Maintains output voltages within tight tolerances under varying loads.
- Ensures adequate power delivery for peak system demands.
Material and Structural Characteristics:
- Heavy-duty construction with efficient thermal management.
- Standard Series 90-70 power module form factor.
Working Principle: The module converts incoming AC or DC power to regulated DC outputs, distributing them through the backplane to all installed modules while monitoring for faults. Installation Requirements:
- Install in a dedicated power supply slot in the rack.
- Connect input power according to wiring diagrams.
- Ensure proper grounding and ventilation.
Usage Notes:
- Verify input voltage settings before applying power.
- Monitor status LEDs for normal operation and fault conditions.
- Provide adequate cooling to avoid overheating under high load.
