GE IS200ECTBG2A
Technical Specifications:
- Brand: General Electric (GE)
- Model: IS200ECTBG2A
- Product Type: Control Terminal Board
- System Platform: GE Mark VI
Functional Features:
- Field Wiring Interface: Provides screw terminals or spring-clamp connections for field cables.
- Signal Routing: Routes signals from field devices to the appropriate I/O board pins.
- Test Points: Includes test points for troubleshooting without disconnecting field wiring.
Application Scenarios:
Mounting in the field wiring compartment of the Mark VI control cabinet to terminate all turbine sensor and actuator cables.
Performance Parameters:
Rated for standard industrial control voltages and currents with adequate creepage and clearance distances.
Material Composition:
Flame-retardant terminal blocks with copper-alloy conductors and a metal mounting frame.
Structural Characteristics:
DIN-rail or panel-mount design with clear terminal labeling and organized wiring ducts.
Working Principle:
Acts as a passive electrical junction, connecting field wires to the I/O board via ribbon cables or backplane connections.
Installation Requirements:
Mount securely in the cabinet. Strip wire to the correct length and torque terminals to specification.
Precautions for Use:
Ensure no stray wire strands cause short circuits. Label all field wires clearly for future maintenance.
