GE TB13015BWE05
Technical Specifications
- Part Number: TB13015BWE05.
- Type: Field Wiring Terminal Block.
- Wire Capacity: Standard industrial control wire gauges.
Functional Features
- Secure Connections: Screw-clamp or spring-clamp terminals for reliable wire retention.
- Organization: Clearly labeled terminals for easy wiring and troubleshooting.
- Modular Design: Can be mounted on panels or directly to control boards.
Application Scenarios
Control panel wiring, RTU field connections, and I/O module interfaces.
Performance Parameters
- Current Rating: Rated for standard control circuit currents.
- Voltage Rating: Suitable for low-voltage control and signal wiring.
Material Composition
High-temperature thermoplastic housing and tin-plated copper contacts.
Structural Characteristics
Compact DIN-rail or panel-mount design with integrated wire guides and labeling areas.
Working Principle
Provides a physical and electrical connection point where external field wires are terminated and routed to internal system electronics.
Installation Requirements
- Strip wires to the correct length to prevent exposed copper.
- Torque terminal screws to the manufacturer’s specification.
Usage Precautions
- Do not over-torque terminals to avoid stripping.
- Use appropriate ferrules for stranded wire.
