Product Brief Introduction: T9852 is dual‑group 8‑channel digital output field termination assembly for Trusted TMR digital output modules. It provides wiring‑termination, surge‑protection and power‑group‑isolation functions for 16‑way digital output signals in dual‑8‑channel groups. Each group equips independent power‑input and fuse‑protection circuit, supports separate power‑source supply for different field‑actuator loops, and cooperates with TMR digital‑output modules to build safety‑critical output signal channels.

Request Quote
Category:

Description

ICS Triplex T9852

Technical Specifications & Performance Parameters:

  • Supported Output Signal: 24 VDC discrete digital output
  • Channel Quantity: Dual‑group 8 channels, total 16 output channels
  • Per‑Channel Continuous Output Current: Max 0.6 A
  • Per‑Group Fuse Rating: 10 A slow‑blow fuse for each 8‑channel group
  • Load Type: Resistive load, inductive solenoid‑valve and relay load
  • Power‑Group Isolation Rating: 1500 V isolation between two 8‑channel power groups
  • Galvanic Isolation Rating: 2500 V reinforced isolation between I/O‑module side and field‑side
  • Power Consumption: Max 4.8 W
  • Protection Mechanisms: Per‑group fuse over‑current protection, channel‑level surge‑suppression, short‑circuit current‑limiting
  • Safety Certification: TÜV IEC 61508 SIL 3, UL, CE
  • Operating Temperature: ‑20 °C ~ +60 °C
  • Storage Temperature: ‑40 °C ~ +85 °C
  • Ambient Humidity: 5 %‑95 % RH non‑condensing
  • Weight: 0.66 kg
  • Form Factor: DIN‑rail‑mounted cabinet‑internal field termination assembly

Functional Features:

  • Dual‑8‑channel digital‑output signal physical transition for Trusted TMR digital‑output modules
  • Independent power‑group design for two 8‑channel groups, separate power‑supply and fuse‑protection
  • Power‑group‑to‑power‑group isolation, restrict fault spread between different field‑actuator power loops
  • Channel‑level surge‑suppression circuit, absorb back‑EMF of inductive loads such as solenoid valves
  • Screw‑type high‑torque wiring terminal blocks for field‑actuator cable termination
  • Dedicated ribbon‑cable completes signal‑transmission between T9852 and rack‑mounted TMR digital‑output module
  • Front‑panel LED indicators, display each channel output‑drive status and power‑group fuse‑fault alarm status
  • Timestamped power‑group fault information transmits to system fault historian via Trusted IMB backplane bus
  • Safety‑related signal voting and core diagnostic logic run on rack‑side TMR I/O module

Working Principle: TMR drive‑signals from Trusted rack‑mounted digital‑output module transmit through dedicated ribbon‑cable to T9852. Signals distribute into two independent 8‑channel power groups. Each group passes independent fuse‑protection circuit and surge‑suppression components, then outputs to field‑side solenoid valves or relay loads through screw‑type terminals. Power‑group‑isolation barrier prevents short‑circuit fault inside one group from spreading to another group. Front‑panel LED indicators reflect channel drive‑state and fuse‑blow fault‑alarm state. Fault‑event information feeds back to rack‑side I/O module, then uploads to main system fault historian. T9852 completes physical‑layer signal transition and fault‑containment work.

Material Composition & Structural Characteristics:

  • Housing: Flame‑retardant high‑strength ABS engineering plastic housing
  • Circuit substrate: Multi‑layer FR‑4 industrial printed circuit board, integrate power‑group‑isolation, surge‑protection and fuse‑holder components
  • Field connection: Screw‑type anti‑loosening wiring terminal blocks and independent power‑input terminals
  • Internal interconnection: Gold‑plated high‑density ribbon‑cable connector
  • Front panel: Embedded multi‑channel LED indicator group, fuse‑replacement access window and channel‑group‑marking area, protection grade IP20

Installation Requirements:

  • Mount T9852 on standard DIN‑rail inside control cabinet, install adjacent to matched Trusted I/O rack
  • Use factory‑specified dedicated ribbon‑cable for connection with Trusted rack‑mounted TMR digital‑output module
  • Two power‑groups can connect to same or different independent 24 VDC field power‑sources
  • Field‑output wiring adopt shielded cables, separate routing from high‑voltage power cables
  • Cable shielding layer single‑end grounding at cabinet ground bus‑bar
  • Cabinet protective ground resistance ≤4 Ω
  • Each power‑group total load‑current cannot exceed rated fuse‑protection capacity
  • Keep installation location away from corrosive‑gas and salt‑fog environment

Application Scenarios:

  • ESD safety‑system solenoid‑valve drive‑signal termination for dual‑power‑group field‑loops
  • Chemical plant safety‑interlock multi‑group actuator output‑signal wiring transition
  • Fire‑gas suppression system safety‑actuator control‑signal physical interface
  • Off‑shore platform safety‑instrumented‑system multi‑group solenoid‑valve output‑terminal unit
  • Power‑plant safety‑shutdown system safety‑relay drive‑signal distribution

Usage Notes:

  • Cut off field‑side power‑group power supply before executing field‑wiring modification or fuse replacement
  • Do not use non‑standard ribbon‑cables for interconnection with Trusted I/O module
  • Module shell disassembly is forbidden; internal circuit exists, zero user‑serviceable spare parts except matched‑specification fuses
  • After module replacement, verify each channel output‑drive function and power‑group fuse‑fault‑detection function
  • Operate strictly within rated operating temperature range
  • Periodically inspect wiring‑terminal fastening torque, fuse‑integrity and field‑loop load‑current status
