LAM 810-091934-00
Technical Specifications:
- Brand: LAM
- Model: 810-091934-00
- Product Type: High-Voltage Switching Module
- System Compatibility: LAM Plasma Processing Systems
Functional Features:
- Safe Power Routing: Provides isolated, high-voltage switching with integrated safety interlocks.
- Arc Protection: Features ultra-fast arc detection and shutdown mechanisms to protect sensitive chamber components.
- Thermal Management: Designed with advanced heat dissipation to handle continuous high-power loads.
Application Scenarios:
Deployed in plasma etch and CVD systems where precise control of high-voltage power delivery is critical for process stability and equipment safety.
Performance Parameters:
- Switching Speed: Nanosecond-level response for arc mitigation.
- Voltage Rating: Rated for continuous high-voltage operation with significant safety margin.
- Isolation Resistance: Exceptional dielectric strength to prevent leakage currents.
Material Composition:
Utilizes high-voltage vacuum relays, specialized high-dielectric insulators, and heavy-duty copper busbars.
Structural Characteristics:
Shielded metal enclosure with high-voltage warning labels, interlock connectors, and forced-air cooling channels.
Working Principle:
Receives low-voltage control signals from the system controller and actuates high-voltage contacts to connect or disconnect power to the load, while continuously monitoring for fault conditions.
Installation Requirements:
Power must be completely disconnected and locked out (LOTO) before installation. All high-voltage connections must be torqued to exact specifications.
Usage Precautions:
Never operate with safety interlocks bypassed. Allow sufficient discharge time before servicing, as internal capacitors retain lethal voltages.
