Motorola MVME-167
Technical Specifications
- Microprocessor: 25 MHz or 33.33 MHz MC68040 with FPU.
- Memory: Onboard DRAM with ECC support.
- Bus: VMEbus interface.
- Interfaces: Serial, Ethernet, and SCSI.
Functional Features
- Built-in FPU.
- Supports VME D64 specification.
- Onboard diagnostic firmware.
- Compatible with multiple real-time operating systems.
Application Scenarios
Process control, motion control, test and measurement, and scientific computing.
Performance Parameters
- Bus: A32/D64.
- Power: Approximately 20W.
Material Composition
Industrial-grade PCB with three-proof coating.
Structural Characteristics
6U VME module with front panel status LEDs.
Working Principle
The MC68040 processor executes control algorithms, utilizing the FPU to accelerate floating-point operations, and communicates with I/O modules via the VME bus.
Installation Requirements
- Insert into the VME chassis and secure with screws.
- Ensure forced air cooling.
- Connect power and ground lines correctly.
Usage Precautions
- Hot-swapping is strictly prohibited.
- Clean dust regularly.
- Shield from strong electromagnetic interference.
