Motorola MVME105
Technical Specifications
- Microprocessor: Motorola 68000 family microprocessor.
- Memory: Onboard DRAM capacity varies by specific production batch.
- Bus Interface: Standard VMEbus interface.
- I/O: Serial and parallel I/O interfaces.
Functional Features
- Representative product of early VME architecture.
- Supports various legacy real-time operating systems.
- Modular design for easy system integration.
Application Scenarios
Legacy industrial automation, laboratory test equipment, and legacy system maintenance.
Performance Parameters
- Bus Support: A16/A24, D16/D32.
- Power: Low power consumption suitable for early-generation chassis.
Material Composition
Industrial-grade PCB with early-generation electronic components.
Structural Characteristics
Standard 6U VME dimensions with P1/P2 backplane connectors.
Working Principle
The processor communicates with the backplane via the VME bus, executing control logic and processing data.
Installation Requirements
- Insert into the VME chassis and secure with screws.
- Ensure adequate cooling.
Usage Precautions
- As a legacy product, strictly verify version compatibility before replacement.
- Observe ESD precautions.
- Avoid operation in harsh environments.
