Description
Motorola MVME147-011A
Technical Specifications
- Microprocessor: MC68030.
- Hardware Revision: Enhanced ‘A’ version.
- Bus: VMEbus system controller/slave.
Functional Features
- Enhanced power management and protection circuits.
- Optimized signal integrity design.
- Compatible with standard MVME712 transition modules.
Application Scenarios
Used in mission-critical systems demanding extreme stability, such as power monitoring, traffic control, and aerospace testing.
Performance Parameters
- Excellent Electromagnetic Compatibility (EMC) performance.
- Supports wide operating temperature ranges.
Material Composition
High-quality flame-retardant PCB materials with gold-plated connector contacts.
Structural Characteristics
Standard 6U VME size, optionally featuring reset and abort switches on the front panel.
Working Principle
The MC68030 collaborates with peripheral chips to communicate with other system modules via the VME bus, executing real-time control algorithms.
Installation Requirements
- Ensure backplane provides stable power.
- Use a torque screwdriver to tighten front-panel mounting screws.
Usage Precautions
- Periodically inspect connector pins for cleanliness.
- Avoid hot-plugging unless explicitly supported.
