Motorola MVME147-022

Motorola MVME147-022

Product Introduction
The MVME147-022 is a model in the MVME147 series optimized for specific industrial applications. It retains the core advantage of operating peripheral controllers without requiring additional backplane modules, reducing system integration costs.

Request Quote
Category:

Description

Motorola MVME147-022

Technical Specifications

  • Core Processor: MC68030 32-bit microprocessor.
  • Bus Interface: A32/D32 VMEbus master/slave interface supporting multi-mode interrupt handling.
  • Peripheral Controllers: On-board SCSI, Ethernet, and serial/parallel interface controllers.
  • Firmware: Built-in MVME147Bug debug monitor firmware providing over 50 debugging and boot commands.

Functional Features

  • High Integration: Highly integrated on-board resources and peripheral controllers free up VME bus slots.
  • Fast Response: Supports multi-mode interrupt handling to ensure rapid response to real-time events.
  • Easy Development: Provides rich development tools, drivers, and on-board debuggers.

Application Scenarios
Suitable for automated test equipment, large PLC system main controllers, robot controllers, medical imaging equipment, and monitors in fields demanding high reliability.

Performance Parameters

  • Power Requirements: +5V DC, typical power consumption between 5-10W.
  • Data Throughput: Supports high-speed data transfer compliant with VME64 standards.

Material Composition
Constructed with high-reliability industrial-grade chips, subjected to strict environmental stress screening to ensure stability under harsh operating conditions.

Structural Characteristics
Standard VME card form factor. Features status indicators on the front panel and interfaces with the chassis backplane via P1/P2 connectors at the rear.

Operating Principle
Acts as an intelligent node接入 the VME system, responding to external events via interrupt mechanisms. Utilizes on-board DMA controllers to independently handle SCSI or Ethernet data transfers, reducing CPU burden.

Installation Requirements
Insert vertically into the VME chassis, applying even pressure to prevent bending of connector pins. Ensure the chassis is properly grounded.

Usage Precautions
Avoid use in environments exceeding specified humidity levels to prevent short circuits caused by condensation. In case of system crashes, the hardware watchdog timer can automatically reset the system.
