Motorola MVME1600-001

Motorola MVME1600-001

Product Introduction
The MVME1600-001 is a 6U VME base board designed to serve as the foundation for the MVME1600 series of embedded controllers. It provides the essential VMEbus interface, power distribution, and I/O routing for processor/memory modules.

Request Quote
Category:

Description

Motorola MVME1600-001

Technical Specifications

  • Bus Interface: IEEE 1014-1987 VMEbus.
  • I/O Routing: P2 connector for transition module interface.
  • Power Distribution: VME P1 power rails.

Functional Features

  • Modular Design: Separates base I/O from processor/memory for flexibility.
  • Transition Module Support: Routes signals to MVME712M or MVME760 modules.
  • VME Compliance: Full A24/A32, D8/D16/D32 support.

Application Scenarios
Custom OEM systems, modular industrial control, and test equipment.

Performance Parameters

  • VME Transfer: Standard VMEbus protocols.
  • Power: +5V, +12V, -12V distribution.

Material Composition
Multi-layer industrial PCB with high-reliability connectors.

Structural Characteristics
Standard 6U VME form factor with P1/P2 connectors.

Working Principle
Routes VMEbus signals from backplane to processor module and transition module.

Installation Requirements

  • Insert into VME chassis and secure.
  • Ensure transition module is properly aligned.
  • Adequate cooling.

Usage Precautions

  • ESD protection.
  • No hot-swapping.
  • Verify connector alignment.
