Description
Motorola PCI-6020TM
Technical Specifications:
- Brand: Motorola
- Model: PCI-6020TM
- Bus Architecture: CompactPCI
- Processor: High-Performance PowerPC Architecture Processor
Functional Features:
- High-Bandwidth Communication: Supports high-speed PCI bus data transmission to meet massive data throughput requirements.
- Hot-Swapping Support: Capable of hot-swapping, allowing module replacement without interrupting system operation.
- Modular Expansion: Provides PMC (PCI Mezzanine Card) expansion slots to support flexible functional customization.
Application Scenarios:
Primarily applied in telecommunications switches, network routers, industrial automation controllers, and test and measurement equipment.
Performance Parameters:
- Operating Temperature: Industrial-grade wide temperature range
- Reliability: Meets telecommunications-grade 99.999% availability requirements
Material Composition:
Manufactured using high-Tg flame-retardant PCB materials. Critical components undergo strict derating design to ensure thermal stability during long-term operation.
Structural Characteristics:
Complies with CompactPCI mechanical standards, featuring front-panel ejector handles for safe insertion and extraction in dense rack environments.
Working Principle:
Achieves high-speed interconnection between the processor and peripherals via PCI bridge chips. System firmware handles hardware initialization and interacts with other nodes through the CompactPCI backplane.
Installation Requirements:
Ensure chassis rails are properly aligned during installation and secure the module using front-panel screws. Pay attention to the airflow direction inside the chassis to avoid thermal dead zones.
Usage Precautions:
Before hot-swapping, verify that the system supports this feature and is configured correctly. Never forcefully insert or remove modules that do not support hot-swapping while energized.
