Description
Motorola MVME162-033
Technical Specifications
- Microprocessor: 32 MHz MC68040 with FPU.
- Memory: 4MB DRAM, 512KB SRAM.
- Network: 10Base-T Ethernet with DMA.
- Storage: SCSI-2 with DMA.
Functional Features
- Dual high-speed DMA channels for Ethernet and SCSI.
- 32 MHz CPU for demanding real-time tasks.
- Full VMEbus system controller support.
- Comprehensive diagnostics and monitoring.
Application Scenarios
Data logging servers, high-speed manufacturing control, and military command systems.
Performance Parameters
- CPU: 32 MHz MC68040.
- I/O: Ethernet + SCSI with DMA.
- Bus: A32/D64 VMEbus.
Material Composition
Ruggedized industrial PCB with conformal coating.
Structural Characteristics
6U VME board with front panel Ethernet and SCSI access.
Working Principle
Simultaneously manages network and storage I/O via DMA while executing real-time control logic on the 32 MHz CPU.
Installation Requirements
- Terminate SCSI bus properly.
- Use shielded Ethernet cables.
- Ensure adequate cooling for 32 MHz operation.
Usage Precautions
- Verify SCSI device IDs and termination.
- Monitor Ethernet link status.
- Perform regular system diagnostics.
