Motorola MVME162-215
Technical Specifications
- Microprocessor: 32 MHz MC68040 with FPU.
- Memory: 4MB DRAM and 512KB SRAM.
- Network: Ethernet interface with DMA support.
- Interfaces: Dual serial ports and four IndustryPack ports.
Functional Features
- 32 MHz high-speed processing.
- Integrated Ethernet for network access.
- VMEbus D64 specification support.
- Onboard diagnostic firmware.
Application Scenarios
Distributed control, data acquisition, and network device management.
Performance Parameters
- Bus: A32/D64 VME master/slave.
- Interrupt: Seven-level interrupt handling.
- Power: Approximately 20W.
Material Composition
Industrial-grade components with conformal coating.
Structural Characteristics
6U double-high VME module with front panel network interface and status LEDs.
Working Principle
The 32 MHz processor manages network I/O, utilizing DMA for high-speed transfers and communicating with the system via the VME bus.
Installation Requirements
- Ensure correct network connections.
- Insert into VME chassis and secure.
- Maintain adequate cooling airflow.
Usage Precautions
- Avoid strong electromagnetic interference.
- Backup configurations regularly.
- Observe ESD precautions.
