Motorola MVME162-216
Technical Specifications
- Microprocessor: 32 MHz MC68040 with FPU.
- Memory: 4MB DRAM and 512KB SRAM.
- Network & Storage: Ethernet and SCSI interfaces, both with DMA.
- Interfaces: Dual serial ports and four IndustryPack ports.
Functional Features
- 32 MHz maximum processing performance.
- Comprehensive network and storage integration.
- VMEbus D64 specification support.
- Onboard diagnostic firmware.
Application Scenarios
SCADA servers, data recording and analysis, telecommunications, and military/aerospace ground equipment.
Performance Parameters
- Bus: A32/D64 VME master/slave.
- Interrupt: Seven-level interrupt handling.
- Power: Approximately 20W.
Material Composition
Industrial-grade components with conformal coating.
Structural Characteristics
6U double-high VME module with front panel network and SCSI interfaces.
Working Principle
The 32 MHz processor coordinates network and storage I/O, leveraging DMA for high-speed data transfers while communicating with other system modules via the VME bus.
Installation Requirements
- Verify correct network and SCSI connections.
- Insert into VME chassis and secure.
- Ensure forced air cooling.
Usage Precautions
- Avoid strong electromagnetic interference.
- Backup system and data regularly.
- Follow ESD handling procedures.
