Description
Motorola MVME162-532A
Technical Specifications
- Processor: MC68040 series.
- Memory: DRAM with parity protection.
- Communication: Multiple serial ports, optional Ethernet.
- Non-Volatile Storage: NVRAM and RTC.
Functional Features
- Wide-Temperature Operation: Supports extreme operating temperatures from -40°C to +85°C.
- Vibration Resistance: Complies with MIL-STD-810 anti-vibration standards.
- Remote Monitoring: Supports remote monitoring of operational status via network.
- High Reliability: Extremely high MTBF, suitable for unattended environments.
Application Scenarios
Aerospace, military ground systems, field exploration equipment, and flight control and navigation systems.
Performance Parameters
- Humidity: 5% to 95% non-condensing.
- Operating Temperature: -40°C to +85°C.
Material Composition
Ruggedized design with conformal-coated PCB and gold-plated connectors.
Structural Characteristics
Sturdy metal front panel with locking mechanisms, standard 6U VME size.
Working Principle
Stably runs RTOS in extreme environments, executes predetermined control logic, and reports data via redundant communication links.
Installation Requirements
- Ensure good chassis sealing to prevent moisture intrusion.
- Use lock washers to secure the module.
Usage Precautions
- Allow sufficient warm-up time during cold-temperature startups.
- Regularly inspect the sealing gaskets of front-panel connectors.
