Motorola MVME167-004B
Technical Specifications:
- Brand: Motorola
- Model: MVME167-004B
- Product Positioning: Enhanced High-Capacity VME SBC
- Core Configuration: MC68040 33MHz Processor with 128MB ECC DRAM
Functional Features:
- Seamless Upgrade: Direct drop-in replacement for the 004A model with no system reconfiguration required.
- Deep Diagnostics: Comprehensive self-test and fault logging capabilities for rapid troubleshooting.
- Hardware Watchdog: Built-in independent hardware watchdog timer automatically resets the system in case of a deadlock.
Application Scenarios:
Deployed in critical infrastructure monitoring, large-scale automated testing platforms, and precision medical laboratory automation equipment.
Performance Parameters:
- Processing Redundancy: Higher instruction execution throughput with microsecond-level interrupt response latency.
- System Uptime: Maximized Mean Time Between Failures (MTBF) in harsh conditions.
Material Composition:
Industrial-grade components with strict impedance control and signal integrity testing on the PCB.
Structural Characteristics:
6U VME standard size with front panel debug serial ports, status indicator LEDs, and physical control switches.
Working Principle:
Acts as the core node in a distributed control system, periodically scanning field I/O states, executing PID regulation or sequential logic control programs, and distributing control results via the backplane bus.
Installation Requirements:
Ensure proper alignment with chassis guides and secure tightening of front panel screws. Configure I/O scaling parameters strictly to prevent output signal over-limiting.
Usage Precautions:
Always wear an anti-static wrist strap during handling. Never insert or remove the module while power is applied to avoid catastrophic component damage.
