Description
Motorola MVME167-RTMX
Technical Specifications
- Function: Real-time I/O expansion.
- Interfaces: Additional serial, parallel, and timing interfaces.
- Compatibility: Designed for MVME167 series SBCs.
- Features: Hardware-timed I/O and interrupt generation.
Functional Features
- Deterministic I/O: Hardware-timed inputs and outputs for precise control.
- Interrupt Generation: Programmable interrupt sources for real-time events.
- Expansion: Adds I/O capacity without consuming additional VME slots.
- Real-Time Clock: High-resolution timing for synchronization.
Application Scenarios
Used in motion control, process automation, and real-time data acquisition.
Performance Parameters
- Timing Resolution: Microsecond-level I/O timing.
- Interrupt Latency: Minimal hardware interrupt response time.
Material Composition
Industrial-grade PCB with high-reliability I/O drivers and connectors.
Structural Characteristics
Compact expansion module that attaches to the MVME167 SBC or mounts in an adjacent VME slot.
Working Principle
Communicates with the MVME167 SBC via the local bus or VME backplane, providing hardware-timed I/O operations independent of the main processor.
Installation Requirements
Attach to the MVME167 SBC or install in a VME slot. Configure I/O addresses via jumpers or software.
Usage Precautions
Verify I/O address conflicts before installation. Ensure proper grounding for I/O signals.
