Description
Motorola MVME172-213A
Technical Specifications
- Microprocessor: MC68060 processor.
- Memory: ECC-protected SDRAM.
- Storage: Battery-backed SRAM/NVRAM with RTC.
- Power: Standard VME power rails.
Functional Features
- Enhanced Reliability: Improved component selection for extended MTBF.
- Comprehensive I/O: Ethernet, SCSI, serial, and parallel ports with DMA.
- System Control: VMEbus system controller with block transfer support.
Application Scenarios
- Mission-Critical Control: Power generation, steel mills, chemical processing.
- Legacy Upgrades: Direct replacement for older MVME167 systems.
- Test Equipment: Automated test and measurement systems.
Performance Parameters
- Operating Temperature: 0°C to 55°C with forced air cooling.
- Storage Temperature: -40°C to +85°C.
- Vibration: Industrial-grade shock and vibration resistance.
Material Composition
- Premium industrial components, multi-layer PCB, lithium battery.
Structural Characteristics
- Form Factor: 6U VMEbus double-high.
- Dimensions: Standard VME 6U footprint.
Working Principle
The MC68060 processor utilizes integrated cache and DMA controllers to manage high-speed data flows between ECC memory, VMEbus, and peripheral interfaces.
Installation Requirements
- Requires 6U VME chassis with forced-air cooling. Ensure proper mechanical retention and grounding.
Usage Precautions
- Strict ESD compliance. Handle lithium battery with care. Verify cooling airflow before operation.
