Description
Motorola MVME172213
Technical Specifications
- Microprocessor: MC68060 processor.
- Memory: ECC-protected SDRAM.
- Storage: Battery-backed SRAM/NVRAM.
- Power: Standard VME power requirements.
Functional Features
- Custom Configuration: Tailored for specific OEM system integration.
- High-Speed I/O: Ethernet and SCSI with DMA support.
- System Control: VMEbus system controller capabilities.
Application Scenarios
- OEM Equipment: Custom industrial machinery and control panels.
- Process Control: Dedicated control nodes in manufacturing.
Performance Parameters
- Operating Temperature: 0°C to 55°C with forced air cooling.
- Storage Temperature: -40°C to +85°C.
Material Composition
- Industrial-grade components, multi-layer PCB, lithium battery.
Structural Characteristics
- Form Factor: 6U VMEbus.
- Dimensions: Standard VME 6U mechanical specifications.
Working Principle
Operates identically to the MVME172 series, utilizing the MC68060 processor and ASIC-based bus management for real-time control.
Installation Requirements
- Requires standard 6U VME chassis with forced-air cooling.
Usage Precautions
- Observe ESD precautions. Verify specific configuration parameters match the target application before deployment.
