Motorola MVME715P
Technical Specifications:
- Brand: Motorola
- Model: MVME715P
- Type: IndustryPack Carrier Board
- Slot Configuration: Supports multiple groups of IndustryPack modules
Functional Features:
- High-Density I/O: Provides maximized I/O density within a single VME slot.
- Enhanced DMA Support: Optimizes data transfer efficiency between the VME master controller and the carrier.
- Wide Temperature Adaptability: Supports industrial-grade wide temperature ranges for harsh field environments.
Application Scenarios:
Distributed I/O stations, remote data acquisition, and control systems requiring extensive sensor integration.
Performance Parameters:
- Interrupt Handling: Supports mapping of IndustryPack interrupts to the VME bus
- Address Space: Configurable A16/A24/A32 address windows
Material Composition:
Industrial-grade PCB and connectors to ensure contact reliability during long-term operation.
Structural Characteristics:
Standard 6U VME size with precise front panel cutouts for convenient field wiring and maintenance.
Working Principle:
Acts as a bridge between the VME bus and IndustryPack modules, providing address decoding, data buffering, and interrupt routing functions.
Installation Requirements:
Observe anti-static precautions when installing IP modules. Ensure securing screws are tightened to prevent poor contact due to vibration.
Usage Precautions:
When configuring VME addresses, avoid overlapping with the address space of other boards in the system.
