Description
Motorola MVME172233
Technical Specifications
- Microprocessor: High-speed MC68060 32-bit processor.
- Memory: Synchronous DRAM with ECC protection.
- Storage: Battery-backed SRAM and NVRAM with RTC.
- Power: Standard VME +5Vdc, +12Vdc, -12Vdc rails.
Functional Features
- Advanced CPU: MC68060 provides superior integer and floating-point performance.
- VME System Controller: Full support for VMEbus arbitration and block transfers.
- Integrated I/O: Ethernet, SCSI, serial ports, and parallel port with DMA.
Application Scenarios
- Industrial Automation: Next-generation DCS and PLC systems.
- Test & Measurement: Automated test equipment (ATE).
- Medical Imaging: Data acquisition and processing modules.
Performance Parameters
- Operating Temperature: 0°C to 55°C with forced air cooling.
- Storage Temperature: -40°C to +85°C.
- Bus Performance: High-bandwidth VMEbus transfers.
Material Composition
- Industrial-grade electronic components, precision PCB, and lithium backup battery.
Structural Characteristics
- Form Factor: 6U VMEbus double-high board.
- Dimensions: Conforms to IEEE 1014-87 standards.
Working Principle
The MC68060 processor executes instructions with integrated cache, managing system resources via dedicated ASICs and DMA controllers for optimal real-time performance.
Installation Requirements
- Install in a compatible 6U VME chassis with adequate forced-air cooling and proper grounding.
Usage Precautions
- Follow standard ESD procedures. Ensure proper seating in the VME connector to avoid pin damage.
