Description
Motorola MVME172P-642LSE
Technical Specifications
- Processor: 60 MHz MC68060 32-bit microprocessor.
- Memory: 16 MB SDRAM with ECC (Error-Correcting Code) protection.
- Storage: 2 MB Flash memory and 128 KB battery-backed SRAM.
- Interfaces: Dual EIA-232-D serial ports, optional SCSI and Ethernet interfaces.
Functional Features
- High Data Integrity: Hardware-level ECC memory protection prevents data corruption during critical operations.
- Flexible Expansion: Supports IndustryPack (IP) modules for additional custom I/O capabilities.
- Real-Time Performance: Optimized hardware architecture ensures deterministic response for industrial control tasks.
Application Scenarios
Extensively deployed in aerospace test benches, defense radar systems, semiconductor manufacturing equipment, and critical industrial process control.
Performance Parameters
- Processing Power: 60 MHz main frequency provides ample computing power for complex control logic.
- Bus Bandwidth: Fully utilizes VME64 bus bandwidth for high-speed data throughput.
- Environmental Tolerance: Supports extended temperature ranges for extreme industrial environments.
Material Composition
Constructed with multi-layer industrial-grade PCBs. Core components are rigorously screened for anti-vibration and anti-shock capabilities.
Structural Characteristics
Standard 6U VME form factor. The front panel includes status indicator LEDs and debug interfaces, while the rear features precision VME connectors.
Working Principle
Communicates via the VME bus to execute operating systems and applications stored in Flash or SDRAM, coordinating peripheral devices to complete control tasks.
Installation Requirements
Must be installed in a standard VME chassis and backplane. Ensure connectors are fully seated and secured with screws to prevent loosening.
Usage Precautions
Always wear an anti-static wrist strap during handling. Ensure adequate chassis cooling and disconnect system power before inserting or removing the module.
